Newland X800 Portable POS

Device Technical Specifications

Core System & Performance

• OS: Android 10.x

• Processor:

  • AP: Octa-Core Cortex A53, 1.8GHz

  • SP: Arm Cortex M3 security core

• Memory: * Standard: 2GB LPDDR4 + 16GB eMMC

• Optional: 3GB LPDDR4 + 32GB eMMC OR 4GB LPDDR4 + 64GB eMMC

• Expansion: MicroSD card slot (supports up to 256GB)

Dual Display System

• Main Display: 8-inch portrait IPS display, $800 \times 1280$ resolution, capacitive multi-touch screen.

• Customer Display: 5-inch landscape IPS display, $800 \times 480$ resolution, capacitive multi-touch screen.

Connectivity & Positioning

• Wireless: * 4G / 3G / 2G

  • Wi-Fi (802.11 a/b/g/n/ac) 2.4G & 5G

  • Bluetooth 2.1 EDR / 3.0 HS / 4.2 LE

• Positioning: GPS / BEIDOU / GLONASS / GALILEO / QZSS / SBAS

Payment & Card Readers

• Magnetic Card Reader: Triple track, bi-directional, conforming to ISO 7810/7811/7813.

• Smart Card Reader: EMV L1/L2, conforming to ISO 7816, 1.8V/3V/5V, synchronous & asynchronous, T=0 & T=1.

• Contactless Card Reader: EMV Contactless L1, conforming to ISO 14443 Type A/B, Mifare, Felica.

Multimedia & Input

• Cameras: * Front: 2 MP fixed focal camera (supports 1D/2D code payment).

  • Rear: 2 MP fixed focal camera (supports 1D/2D code payment).

• Audio: 1 x Speaker, 1 x Microphone, 1 x Audio JACK; supports audio recording and media play.

• Keypad: Secure virtual keypad for PIN entry, 1 x power button.

Hardware & Power

• Printer: High-speed thermal printer, 80mm/s; Paper roll diameter: 50mm; Paper width: 58mm.

• Battery: Li-ion battery, 3.8V / 6000mAh / 22.8Wh.

• Ports: 1 x Type-C, USB 2.0 OTG, Pogo Pins.

• Card Slots: * Standard: 2 x SIM, 1 x SAM, 1 x SD

  • Optional: 1 x SIM, 2 x SAM, 1 x SD

• Power Supply: Input: 100-240V AC 50/60Hz; Output: 5.0V DC, 3A.

Physical & Environmental

• Dimensions: 274.9mm (L) * 123.4mm (W) * 101.6mm (H)

• Weight: 895g (including battery).

• Operating Temp: -10°C to 50°C (14°F to 122°F).

  • Note: Charging below 0°C is not recommended.

• Storage Temp: -20°C to 70°C (-4°F to 158°F).

• Humidity: 5% to 93% (Non-condensing).

Accessories & Certifications

• Docking Station: Charging base included.

• Expansion HUB (Optional): 1 x RS232, 2 x USB-A, 1 x Type-C, 1 x Ethernet (RJ45), 1 x Cash drawer port.
